Indomarine BWP — enhanced complete sheet with clean grain and face printing
See the product in detail.
GSM Enterprises · YouTubeProduct overview from GSM Enterprises. Current GSM specification: BWP IS:303 2024, treated red eucalyptus core and 8 × 4 ft sheets.
Indomarine
Indomarine BWP
Treated red eucalyptus BWP plywood with a Gurjan face for interior and exterior furniture, kitchens, bathroom panels and décor.
- Grade
- BWP Grade IS:303 2024
- Thickness
- 19mm, 16mm, 12mm, 09mm, 06mm
- Sheet size
- 8'x4'
- Warranty
- 25 years
Product details
- Core: Treated Red Eucalyptus
- Face: Gurjan Face c+ Grade
- Resin: E1 BWP PF Resin
- Thickness tolerance: ± 0.5mm
Applications
- Interior and exterior furniture and decor
- partitions
- panelling
- doors
- kitchen panels
- bathroom panels
Construction & performance
- Construction: Full core panels to reduce gaps; 100% composed core.
- Calibration: Single-line calibrated plywood for consistent thickness and a smooth surface.
- Manufacturing: High-density pressing using high pressure and temperature.
- Protection: Glue Line Protection (GLP), ACC treatment and integrated core protection.
- Preservative treatment: Insecticide and fungicide treatment for durability; non-toxic preservatives.
- Biological resistance: Borer and termite protection; antibacterial protection.
- Stability: High dimensional stability with resistance to bending and warping.
- Fastener holding: High nail-holding and screw-holding capacity.
- Surface quality: Smooth finish; SSS — Strength, Smooth Surface.
- Usage: Suitable for interior and exterior applications, including kitchens and wet areas, as confirmed by GSM.
- Quality control: In-house laboratory checks.
- Environmental marking: E1 emission class and FSC marking.
- Manufacturer credentials: ISO 14001:2004 environmental management certification for manufacture and marketing of wood-based products.
- Industry membership: Lifetime member of IPIRTI — Indian Plywood Industries Research & Training Institute, Bengaluru, Karnataka.
Technical specifications
- Moisture content: 7% (requirement: 5–15%).
- Dry-state glue adhesion / glue shear strength: Average 1682 N; minimum individual 1303 N (requirements: 1350 N and 1100 N respectively).
- Water-resistance test / glue shear strength: Average 1409 N; minimum individual 1130 N (requirements: 1000 N and 800 N respectively).
- Mycological test / glue shear strength: Average 1456 N; minimum individual 1015 N (requirements: 1000 N and 800 N respectively).
- Static bending — modulus of elasticity (MOE), along face grain: Average 9773 N; minimum individual 8910 N (requirements: 7500 N and 6700 N respectively).
- Static bending — MOE, across face grain: Average 9970 N; minimum individual 9250 N (requirements: 4000 N and 3600 N respectively).
- Static bending — modulus of rupture (MOR), along face grain: Average 86.6 N; minimum individual 75.4 N (requirements: 50 N and 45 N respectively).
- Static bending — MOR, across face grain: Average 58.2 N; minimum individual 52.2 N (requirements: 30 N and 27 N respectively).
- Tensile strength parallel to face-veneer grain: 65.4 N (minimum requirement: 42.0 N).
- Tensile strength perpendicular to face-veneer grain: 53.4 N (minimum requirement: 25.0 N).
- Combined tensile strength in both directions: 118.8 N (minimum requirement: 84.5 N).
- Preservative retention: 14.38 kg (requirement: 12 kg).
- Technical units: N and kg are reproduced exactly as supplied; area or volume denominators are not specified.
